DC UPS Din Rail Mount units with DC Input

  • DC UPS Units with 24VDC , 12VDC Input
  • Current ratings from 10A to 20A
  • Compact buffering solutions



  • DCW20 - DC/DC UPS 12V 24V 48V 20A

  • Digital power regulation, LCD interface
  • Integrated battery charger for 12V 24V and 48V multi- chemistry batteries with a charging current up to 20A
  • Can operate with super capacitors modules
  • Battery voltage independent of input and output voltage
  • 20A or 960W rated load
  • Multiple protections
  • Measures voltages and currents on input, output and battery
  • Battery protection against reverse polarity connection and overcurrent
  • Battery health monitoring system: measuring battery internal resistance, battery temperature, charge/discharge cycles and Coulomb counter
  • User settable maximum backup time
  • Auxiliary output with same voltage as battery (5A max.), protected against overcurrent/shortcircuit

  • Part #: DCW20

    Qty:


    DCU20 - DC/DC UPS 12V 24V 20A

  • Digital Power regulation, LCD interface
  • Multiple user settable parameters
  • BI VOLTAGE: 12V or 24V (intermediate voltages possible)
  • Battery chemistry: Lead acid, nickel and lithium
  • Maximum battery capacity 150Ah
  • Load current: 20 A Max
  • Multiple protections
  • Cold start
  • Automatic sensing of input voltage, load current and battery current
  • Battery protection against reverse polarity connection and overcurrent
  • Battery health monitoring system: measuring battery internal resistance, battery temperature, charge/discharge cycles and Coulomb counter
  • User settable maximum backup time

  • Part #: DCU20

    Qty:


    NUPS24 - DC/DC UPS 24V 10A

  • Low cost DC-UPS with charging function of a 24Vdc battery
  • Suitable for power supplies with adjustable output
  • Allows to feed the load and to charge the battery simultaneously
  • Built-it battery overcurrent protection fuse
  • Battery deep discharge protection
  • To be used with lead acid batteries
  • Instantaneous LOAD switch to BACKUP mode

  • Part #: NUPS24

    Qty:


    NUPS12 - DC/DC UPS 12V 10A

  • Low cost DC-UPS with charging function of a 12Vdc battery
  • Suitable for power supplies with adjustable output
  • Allows to feed the load and to charge the battery simultaneously
  • Built-it battery overcurrent protection fuse
  • Battery deep discharge protection
  • To be used with lead acid batteries
  • Instantaneous LOAD switch to BACKUP mode

  • Part #: NUPS12

    Qty:


    BUFFER MODULE 12V 24V 48V 72V 500W 0.3S

  • High efficiency and extremely compact size
  • Wide voltage range: 12 to 85 Vdc
  • Self tracking DC BUS voltage
  • > 150 Joules energy storage
  • Compact size
  • Reliable topology, based on standard electrolytic capacitors
  • Dry contacts for status signalling and opto-isolated input for INHIBIT
  • Digital Power regulation
  • Multiple protections, integrated safety circuit that disconnects the capacitor bank in case of internal failure
  • Can boost the peak power of the DC supply
  • Parallelable for power and backup time increase

  • Part #: BU150

    Qty:


    12V Ultracapacitor Battery Replacement 7.6KJ

  • Compact size, standard enclosure shape
  • Reliable topology, based on new technology of Electric Double Layer Capacitors
  • Capacity = 7.6 kJ 60 Farad 12 Volts
  • Replaces 12V batteries for short term backup applications
  • Extended operating temperature for high reliability
  • Multiple parallel and series connection possibilities for voltage and/or current increase
  • Reverse polarity and overcurrent protections
  • Pluggable connectors
  • Up to 85°C operating temperature

  • Part #: NCP12

    Qty:


    UB10.241

    DC/DC UPS System Input: 24VDC Output: 24VDC 10A Battery Voltage: 12VDC

    Part #: UB10.241

    Qty:


    UB10.245

    DC/DC UPS System Input: 24VDC Dual Output: 24VDC 10A 12V 5A Battery Voltage: 12VDC

    Part #: UB10.245

    Qty:


    UB20.241

    DC/DC UPS System Input: 24VDC Output: 24VDC 20A Battery Voltage: 24VDC

    Part #: UB20.241

    Qty:


    UB10.242

    DC UPS System 24V 10A

    Part #: UB10.242

    Qty:


    UBC10.241 DC UPS 24V 10A with battery 5AH

    DIN Rail Mount UPS Power Supply - 24 to 28V Input - Output: 24V dc 10A with integrated 5AH battery

    Part #: UBC10.241

    Qty:


    CTEC-1203-1-DC

    DCDC UPS Input: 12VDC Output: 12VDC 3A with 1000 WS storage Built in Ultracapcitor Dimensions: h x w x d (mm) 92 5x60x116 Weight: 0.55KG

    Part #: CTEC-1203-1-DC

    Qty:


    CTEC-2403-0.5-DC

    DCDC UPS Input: 24VDC Output: 24VDC 3A with 500 WS storage Built in Ultracapcitor Dimensions: h x w x d (mm) 92 5x60x116 Weight: 0.5KG

    Part #: CTEC-2403-0.5-DC

    Qty:


    CTEC-2403-1-DC

    DCDC UPS Input: 24VDC Output: 24VDC 3A with 1000 WS storage Built in Ultracapcitor Dimensions: h x w x d (mm) 92 5x60x116 Weight: 0.5KG

    Part #: CTEC-2403-1-DC

    Qty:


    CTEC-2405-5-DC

    DCDC UPS Input: 12V/24VDC Output: 12V/24VDC 5A with 5000 WS storage Built in Ultracapcitor Dimensions: h x w x d (mm) 163x114x145 Weight: 1.7KG

    Part #: CTEC-2405-5-DC

    Qty:


    CTEC-2408-20-DC

    DCDC UPS Input: 12V/24VDC Output: 24VDC 8A with 20 KWS storage Built in Ultracapcitor Dimensions: h x w x d (mm) 163x185x145 Weight: 3.5KG

    Part #: CTEC-2408-20-DC

    Qty:


    CTEC-2410-1-DC

    DCDC UPS Input: 12V/24VDC Output: 24VDC 10A with 1 KWS storage Built in Ultracapcitor Dimensions: h x w x d (mm) 165x70x138 Weight: 1.2KG

    Part #: CTEC-2410-1-DC

    Qty:


    CTEC-2410-10-DC

    DCDC UPS Input: 12V/24VDC Output: 24VDC 10A with 10 KWS storage Built in Ultracapcitor Dimensions: h x w x d (mm) 163x114x145 Weight: 2.1KG

    Part #: CTEC-2410-10-DC

    Qty:


    CTEC-2420-8-DC

    DCDC UPS Input: 24VDC Output: 24VDC 20A with 8 KWS storage Built in Ultracapcitor Dimensions: h x w x d (mm) 192x84x192 Weight: 2.2KG

    Part #: CTEC-2420-8-DC

    Qty:


    CTEC-1225-0.5-DC-UR

    DCDC UPS Input: 12VDC Output: 12VDC 25A Unregulated with 0.5 KWS storage Built in Ultracapcitor Dimensions: h x w x d (mm) 123x65x145 Weight: 0.7KG

    Part #: CTEC-1225-0.5-DC-UR

    Qty:


    CTEC-2425-1.2-DC-UR

    DCDC UPS Input: 24VDC Output: 24VDC 25A Unregulated with 0.5 KWS storage Built in Ultracapcitor Dimensions: h x w x d (mm) 123x65x145 Weight: 0.8KG

    Part #: CTEC-2425-1.2-DC-UR

    Qty:


    CTEC-2440-4-DC-UR

    DCDC UPS Input: 24VDC Output: 24VDC 40A Unregulated with 4 KWS storage Built in Ultracapcitor Dimensions: h x w x d (mm) 188x84x194 Weight: 2KG

    Part #: CTEC-2440-4-DC-UR

    Qty:


    CTEC-4815-1-DC-UR

    DCDC UPS Input: 48VDC Output: 48VDC 15A Unregulated with 1 KWS storage Built in Ultracapcitor Dimensions: h x w x d (mm) 123x65x145 Weight: 0.8KG

    Part #: CTEC-4815-1-DC-UR

    Qty:
